Descrizione
The SkyRC e680 universal charger is easy to use and at the same time offers a variety of features.
All common battery types such as LiPo / LiIon / LiFe / LiHV / NiMH / NICd / Pb and the system battery of the DJI Mavic are supported by the microprocessor-controlled SkyRC e680.
All common loading and unloading modes such as Charge, Ballance Charge, Fast Charge, Storage and Discharge are mastered. Especially in the Pb range, the charger offers an AGM and cold charging mode. DJI Mavic batteries are also supported with their own mode (optional charging cable SK600023-06 required).
In addition, the e680 can supply consumers such as tire grinders, LED pit lamps, motor testers, etc. directly with 13.8V and max 80W power with the power supply function.
Features:
Excellent performance data max. 8A / 80W
Integrated power supply function 13.8V / 80W
10 profile memories
TVC Terminal Voltage Control
Internal balancer with XH connection
Simplest 4 button operation
Lead-acid battery AGM and cold charging mode
Suitable for LiPo / LiHV / Lilon / LiFe / NiCd / NiMH / Pb and DJI Mavic batteries
Technical specifications:
Input voltage AC: 100V -240V
Input voltage DC: 11V - 18V
Charging power: 80W
Discharge power: 10W
Charging current: 0.1A - 8.0A
Discharge current: 0.1A - 2.0A
Balancer current: max. 300mAh
Number of cells: LiPo / LiFe / LiIon / LiHV 1s - 6s
Number of cells: NiMH / NiCd 1s - 15s
Pb battery voltage: 2V - 20V
Weight: 390g
Dimensions: 135x110x60mm
