WTS Black Pro Transponder - RC4 Compatibile

Descrizione

The WTS Transponder is compatible with all RC System including RC Version 4 Decoders with Firmware 4.4 or lower. Dimesions: 19x19x6mm Weight: 4gr Temperature Range: 0-50 degree (Celsius) Humidity: max 90% relative Signal Transfer: Magnetic Induction Transponder Position: Horizontal Max Height 15cm Power Feed: RX Channel or Battery Connection Plug: Standard Servo Plug Operating Voltage: 3V-16V DC (Reverse Polarity Protected) Power Consumption: 14mAh @ 6V Display LED: Ultra-Bright RED The WTS Transponder is compatible with all RC System including RC Version 4 Decoders with Firmware 4.4 or lower. Operation is purely lap counting and timing using its 7 DIGIT ID number. The Transponder is ready to be used right away simply by connecting to a Battery or plugging into a free Reciver Channel or BATT Socket. WTS Power Cable can be easily replaced. Preheat black part of Transponder to 80 degree (Celsius) and slowly remove PCB from Case. Solder new Cable to PCB pads. Be sure to respect the polarity. Insert PCB agian into the Case. Use Hot Glue to close the Case.
