Descrizione
ONLY Compatible RF with FH5
Compatible Response Mode with SUR, SSR, SHR, NOR
SSL CODE5/CODE10 Function
Weight: 382 g
Power source: AAA Battery x 3
H5 RF mode compatible
FH5 RF mode is higher resolution than former FH4 RF mode.
Also, MT-5 installed SUR (SANWA ULTRA RESPONSE) Mode
which is faster mode than SSR (SANWA SUPER RESPONSE) mode
which was installed in MT-44.
Combination with FH5 RF mode and SUR mode will give great smooth feeling.
Compatible receivers are RX-491, RX492, RX-493, and RX-493i.
(FH3 and FH4 compatible receivers as RX-38*, 45*, 46*, 47*, and 48* cannot be used for MT-5)
Indicator Function compatible
Indicator function can be checked signal strength connected transmitter.
Using with transmitter which installed Indicator function can be used for finding problems
as incorrect receiver placing and finding the best receiver position for transmitter.
By SANWA technical development, indicator function can be checked signal strength without any effect with response.
HIGH RESOLUTION DISPLAY
The same detailed dot as MT-44 enables so clear display.
Three kind of telemetry data can be displayed simultaneously because of gray scale display.
BEST POSITION FOR STEERING / THROTTLE
Steering/Throttle is arranged in the best position for operation.
Drop Down is used as standard postion.
THREE AAA BATTERIES
Three AAA batteries allows to be not only compact but also light.
USB CHARGE
When used with optional Li-Po 1 cell battery, weight become lighter and it can be changed from USB input.
SYSTEM: 2.4GHz FH5
4CH
Transmitter: TX-491
Receiver: RX-493i
[New features]
FH-5 RF MODE (SUR response mode compatible)
Indicator Function
[Other functions]
Movable Carrying Handle
Quick Setup Wizard
Safety Link
Racing Mode
Customized Menu
Micro SD card-compatible
Telemetry Switch
Clock
Circumstance Temperature Display
CSV Output for LOG data
CODE 10-compatible (Naming support)
Simultaneous three telemetry data display
Three AAA Batteries
Li-Po 1 cell-compatible (USB change support)
Large full dot LCD monitor
Wight LED back light
Full adjustable trigger
Telemetry function
Built-in antenna
Multi Menu Selector
ST/TH Tension Adjuster
Dual Rate
End Point Adjuster
Anti-lock Brake
Servo Speed
Offset
Trim/Sub trim
Servo Reverse
Curve (Exponential/Adjustable Rate Control)
AUX1 (Movement type for 3CH. it's the same as MT-4S function)
AUX2 (Movement type for 4CH. it's the same as MT-4S function)
Fail safe (power/battery)
Timer (lap/ interval/ down)
Lap
Logger
20 model memory (when used with SD card, 250 models is available)
Model Name (12 letters)
Model (Select/Clear/Copy)
Direct Model Select
Trim Type (Center/parallel)
Throttle Type (70:30/50:50)
RF MODE Setting (FH4T/FH3)
Response Mode Setting (NOR/SHR/SSR)*
Key Assign(SW/TRIM/DIAL/LEVER)
AUX TYPE SETTING
- CODE AUX (w/ Naming function)
- STEP AUX (Step 1 - 100)
- POINT AUX (2 - 6 point)
- 4WS MIXING (Front/Rear/Normal(coordinate phase)/Reverse(opposite phase))
- MOA MIXING (FWD/4WD/RWD)
- AUX MIXING (ST MIXING/ TH MIXING)
Buzzer(scale/volume)
Transmitter Battery Alarm
LCD Contrast
Volume Adjustment
Mechanical Rudder Angle
Small Grip Pad
Compatible Receivers:RX-491, RX-492, RX-493, RX-493i
Telemetry-compatible
