Ezrun MINI28 Manual
The Ezrun MINI28 ESC offers everything You need for fully experiencing 1:28 RC care. With over 25 different adjustable parameters, the MINI28 shows that it allows the car to handle numerous situations with ease. So if you like to drive a Mini and use a brushless motor, this Hobbywing ESC is the ideal addition to Your setup.
Adjustable parameters
- General
Running Mode, max. forward force, max. reverse force, cutoff voltage, ESC thermal protection, motor rotation
- Throttle Control
Throttle Rate Control, Neutral Range, Initial Throttle Corce, Coat, PWM drive frequencym Softening value, Softening range
- Brake Control
Drag brake force, max. brake force, brake rate control, brake frequency
- Timing
Boost timing, boost timing activation, boost start RPM, boost end RPM, turbo timing, turbo delay, turbo increase rate, turbo decrease rate
Features
- Specially developed for use in 1/28 mini racing
- Small and light ESC
- Over 25 different parameters
- Huge improvement in driving experience
- Various built-in protections
- Compatible with LCD G2 programming box and OTA programming module
Technical Specifications
Current (cont./peak): 30A/80A
Motor Type: Brushless Motors
Motor Limit: 1626 Motors
LiPo-/NiMH cells: 2S LiPo
BEC-Output: 6V / 7.4V (adjustable), 3.5A Switch Mode
Dimensions: 22.7x14.2x11.8mm
Weight: 5g (without cable)
Application: 1/28 Mini
Programming Port: Shared with throttle cable
