AGF-RC A62BHS - High Durable Steel Gear 16KG 0.058Sec Super Power Low Profile Brushless RC Servo

Descrizione

The A62BHS digital brushless programmable low profile servo can reach a maximum torque of 16.0 kg-cm and a fast speed of 0.058Sec under the drive of the highest voltage of 8.4V. This high-performance servo is designed with a heat sink CNC case, which can prevent hot and stuffy phenomena when the model is running. In addition, the long-life brushless motor and the silk-smooth double ball bearings support the operation of the internal structure of the servo, which can effectively work with the steel gear precisely.

Feature
High Performance Low Profile Digital Servo
High Precision Steel Gears
Long Lifespan Brushless Motor
Reliable Dual Ball Bearings
Heat Sink Aluminum Case
Water And Dust Resistance
Programmable Digital Circuit
Ideal for 1/12, 1/10 On Road, Touring, Drifting, Boat, Airplane, Robot etc.

Specification
Item: A62BHS
Operating Voltage: 4.8-8.4V
Operating speed: 0.070sec/60° @ 6.0V
Operating speed: 0.065sec/60° @ 7.4V
Operating speed: 0.058sec/60° @ 8.4V
Stall Torque: 13.0 kg-cm (180 oz-in) @ 6.0V
Stall Torque: 14.5 kg-cm (201 oz-in) @ 7.4V
Stall Torque: 16.0 kg-cm (222 oz-in) @ 8.4V
Gear: Steel
Motor: BLS
Size: 40.8*20.2*26.5mm (1.60 x 0.79 x 1.04 in)
Weight: 57.2g
Connector Wire: TYU 200mm/22AWG
