Descrizione
Whether it's 1/10 On-Road or 1/10 Off-Road, the action starts with the Razerten G2 Combo.
The Razerten G2 60A ESC is always the top choice when reliability, efficiency, and durability are paramount.
With extensive adjustment and programming options, it leaves nothing to be desired.
All cables are pre-wired and ready to connect, no soldering required. Paired with the 3000kV Razerten motor, it delivers a sensorless experience with immense power.
The motor's disassemblable CNC machined aluminum housing and precision-balanced rotor with high-quality ball bearings are top-class features.
Features (ESC)
- More compact and modern than its predecessor
- Fully water and dustproof ESC (not applicable to the motor)
- ON/OFF switch with setup button
- S-BEC with 6V and 3A peak current
- Plug and Play, battery and motor connectors pre-soldered
- Multiple protection features: low voltage cutoff, thermal protection, and signal loss protection
- Easy programming via setup button
- Separate programming port, easy connection for optional LED programming card
Features (Motor)
- 4-pole rotor design for high torque and quick response
- CNC machined high-strength aluminum housing for optimal heat dissipation
- Motor winding made of pure, double-insulated copper wire
- Precision ball bearings for smooth operation and longevity
- Highly flexible silicone connection cables with pre-soldered 4mm connectors
- High-strength, polished 3.17mm steel rotor shaft
Technical Specifications
ESC
- Item No. R01225
- Current 60A
- Type Sensorless
- Cells 2-3S LiPo / 6-9 cells NiMH
- Motor Limit 2S 3652/3660 motor, kV = 6000
3S: 3652/3660 motor, kV = 3500
- BEC 6V @ 3A
- Fan Yes, powered by BEC
- Programming Port Yes
- Battery Connection T-Plug
- Motor Connection 4mm
- Dimensions 46 x 36.5 x 35.5mm
- Weight (incl. Cables) 98.2g
- Application 1/10 On-Road, Buggy, Short Course Truck (2WD)
Motor
- Item No. R01230
- kV Rating 3000kV
- Cells 2-3S
- Poles 4
- Outer Diameter 35mm
- Length 52mm
- Shaft Diameter 3.17mm
- Shaft Length 15mm
- Weight (incl. Cables) 198g
- Application 1/10 Onroad, Buggy, light SCT/Truck/MT
Delivery
1x Razer ten G2 ESC with 60A, pre-wired with battery connector and motor connection
1x Razer ten Motor with 3000kV, pre-wired with 4mm connectos
1x Manual
Accessories
R01269 Razer LED Program Box
